055CXV3 - Carbon Fiber Tripod

Made after 2008-05-29
For Serial Number A1351035

Under construction

This version has different parts from the 055XB and 055XPROB

A1 Center Column Lock Knob
A2 Center Sliding Block

B1 Main Casting Top Plate
B2 Main Casting Bottom Plate

C1 Leg Brace & Upper Leg Tube
C2 Leg Extender Release Button

D1 Center Column (not a stock item)
D2 Center Column Plug (not a stock item)

E1 Upper Leg Lock Assy
E2 Upper Snap Lever

F Middle Leg Tube (not a stock item)

G1 Lower Leg Lock Assy
G2 Lower Snap Lock Lever

H Lower Leg Tube (not a stock item)

I1 Rubber Foot (set of 3)
I2 Spike Feet Accessory (set of 3)
J1 Leg Sleeves (set of 3)
J2 Leg Collars (set of 3)

K Cable Clip & Wrench

L Strap Loop
Editor note:

Item numbers listed in the index on the right column may not be shown
on the picture because the part may be obscured or is inside another part or itis
underneath another part and cannot be shown. Click on the link to see the actual Part picture. Links will turn red on "mouse-over' and blue after they have been visited.
