055XDB Version 2 - Aluminum Tripod

Made after 2008-10-15
For Serial Number A1612001

This version has different parts from the 055XB ans 055XPROB




A1 Center Column Lock Knob
A2 Center Sliding Block

B1 Main Casting Top Plate (not a stock item)
B2 Main Casting Bottom Plate (not a stock item)

C1 Leg Brace & Upper Leg Tube
C2 Leg Extender Release Button

D Center Column
D 055XSCC Short Center Column
D1 Center Column Plug
D2 Rubber Spacer
D3 Grub Screw - Single
D3 Grub Screw - 5 Pack
3 grub screws required

E1 Upper Leg Lock Assy
E2 Upper Snap Lever

F Middle Leg Tube

G1 Lower Leg Lock Assy
E1 USED Lower Leg Lock
G2 Lower Snap Lock Lever

H Lower Leg Tube

I Rubber Foot (set of 3)
I1 Spike Feet Accessory (set of 3)

K Strap Loop

Notes: Part C2 was changed from ver 1 to ver 2

Editor note: Item numbers listed in the index on the right column may not be shown
on the picture because the part may be obscured or is inside another part or itis
underneath another part and cannot be shown. Click on the link to see the actual Part
picture. Links will turn red on "mouse-over' and blue after they have been visited.
