190XPROB Version 1 - Aluminum Tripod

Made after 2006-10-25
For Serial Number From A0629812 to A0865401

A1 Center Column Lock Knob
A2 Center Column Brake Shoe

B1 Main Casting Top Plate (not a stock item)
B2 Main Casting Bottom Plate (not a stock item)

C1 Left Side Pro Casting
C2 Pro Bushing
C3 Pro Rotation Bushing
C4 Right Side Pro Casting
C5 Bubble Level

D Center Column Assy

E Leg Brace & Upper Leg Tube

F1 Upper Leg Lock Assy
F2 Upper Snap Lever

G Middle Leg Tube

H1 Lower Leg Lock Assy
H2 Lower Snap Lock Lever

I Lower Leg Tube

J Rubber Foot (set of 3)
J1 Spike Feet Accessory (set of 3)

K Cable Clip & Wrench

L Strap Loop

Notes: Part B1 and B2 were changed from ver 1 to ver 2 and from 2 to 3
Version 2 and 3 added new part E2 which was included in this version B2

Editor note: Item numbers listed in the index on the right column may not
be shown on the picture because the part may be obscured or is inside in
underneath another part and cannot be shown. Click on the link to see the
actual Part picture. Links will turn red on "mouse-over' and blue after they
have been visited.
